N2XH Power cables
  • N2XH Power cables
  • N2XH-O 1x300 RM 0,6/1kV
CE markedVDE certified
flame-retardanthalogen-free
PDF

Power cables; 1x300 RM; N2XH-O; U0/U: 0,6/1 kV; Bare copper; Polyolefin; VDE certified; Fixed installationCopied to clipboard

Add to product comparison

Login for individual price.

Price

5.781,49 €

(5.781,49 €/100 M)

Quantity

Login for the stock enquiry.

Load availability ...



  • Halogen-free and highly flame retardant materials reduce the risk of flame propagation, high smoke density and toxic smoke in the event of a fire.
  • Classified fire behaviour according to EU Directive 305/2011 (BauPVO/CPR) with article number selection on the LAPP website.
  • VDE-certified cable with ◁VDE▷ testing mark for proven reliability and quality.
  • Insulated copper conductors are single or multi-wire, round or sector-shaped.



  • Abbreviations "RE“, "RM“, "SE“, "SM“: R = round conductor form; S = sector-shaped conductor; E = single-wire conductor; M = multi-wire conductor
  • Trade product, not a LAPP product.



  • For the power supply connection to buildings and industrial plants, in compliance with special fire protection requirements.
  • Suitable for energy distribution in power and converter stations.
  • Suitable for use in AC and DC charging infrastructures for electromobility.
  • For fixed installation.
  • For installation on, in or under plaster, in brickwork and in concrete.
  • Durable outer sheath made of halogen-free, thermoplastic polyolefin compound.
  • Suitable for outdoor use, subject to the temperature range and only if protected against direct sunlight.



Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Photographs and graphics are not to scale and do not represent detailed images of the respective products.

The absence of PWIS raw materials does not protect against the potential risk of contamination with substances that interfere with the paint wetting during subsequent handling of the product(s) during transport, storage or further processing after delivery.

If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.

Trade product, not a LAPP product.
