Medium-voltage cable; 1x50 RM; U0/U: 6/10 kV; Aluminium; PE; Shielded; VDE certified; Fixed InstallationCopied to clipboard
Add to product comparison
Price on request
Would you like an individual quotation for this article?
Login for the stock enquiry.
Loading...
Load availability ...
- VDE-certified cable with ◁VDE▷ testing mark for proven reliability and quality according to VDE 0276-620.
- Robust during installation and operation thanks to durable PE outer sheath.
- With additional banding to protect against the ingress of water in the longitudinal direction after mechanical damage. Cross-linked conductive layers above and below the core insulation prevent partial discharges and enable constant operational reliability.
- Available in conductor cross-sections up to 1,000 mm2.
- Available in voltage classes 6/10 (12) kV, 12/20 (24) kV and 18/30 (36) kV.
- Trade product, not a LAPP product.
- Suitable for energy distribution in medium-voltage networks.
- Suitable for use in AC and DC charging infrastructures for electromobility.
- For fixed installation in water, air and soil. In the ground, the minimum installation depth without additional, suitable underground protection is 0.6 m, and at least 0.8 m under roads (according to HD 620/VDE 0276-620 Part 10-C (point 4)).
- Also suitable for installation indoors and in closed installation ducts for energy supplier, industrial and distribution networks, but not flame-retardant according to IEC 60332-1-2.
- Suitable for high mechanical stress due to the PE outer sheath.
- Suitable for outdoor use.
- Use at temperatures down to -40°C possible.
