NAYY-O 1x50 RM 0,6/1kV
  • NAYY-O 1x50 RM 0,6/1kV
  • NAYY-O 1x50 RM 0,6/1kV
CE markedVDE certified
uv-resistant.flame-retardant
PDF

Power cables; 1x50 RM; NAYY-O; U0/U: 0,6/1 kV; Aluminium; PVC; VDE certified; Fixed InstallationCopied to clipboard

Add to product comparison

Price on request

Would you like an individual quotation for this article?

Request price

Quantity

Login for the stock enquiry.

Load availability ...

Benefits

  • Suitable for direct underground installation thanks to tough sheath material (PVC). The robust jacket material protects against harmful environmental influences and chemicals.
  • A common core wrapping made of a filling compound ensures additional strength of the cable.
  • Classified fire behaviour according to EU Directive 305/2011 (BauPVO/CPR) with article number selection on the LAPP website.
  • VDE-certified cable with ◁VDE▷ testing mark for proven reliability and quality.
  • Insulated aluminium conductors are single or multi-wire, round or sector-shaped.
  • Aluminium conductors are lighter and cheaper than copper conductors. They achieve comparable conductivity, provided that at least one to two larger conductor cross-sections are selected.

Comments

  • Abbreviations "RE“, "RM“, "SE“, "SM“: R = round conductor form; S = sector-shaped conductor; E = single-wire conductor; M = multi-wire conductor
  • Trade product, not a Lapp product.

Application

  • Can be used universally for connecting the power supply in buildings and industrial facilities.
  • Suitable for energy distribution in power and converter stations.
  • Suitable for use in AC and DC charging infrastructures for electromobility.
  • For fixed installation in water, air, soil and concrete. In the ground, the minimum installation depth without additional, suitable protection is 0.6 m, and at least 0.8 m under roads.
  • Can be used in dry, damp and wet environments.
  • Suitable for medium mechanical stress.
  • Suitable for outdoor use, subject to the temperature range.

Notes

Unless specified otherwise, the product values shown are rated values at room temperature. You can receive further values, such as tolerances, upon request if they are available and have been released for publication.

Photographs and graphics are not to scale and do not represent detailed images of the respective products.

The absence of PWIS raw materials does not protect against the potential risk of contamination with substances that interfere with the paint wetting during subsequent handling of the product(s) during transport, storage or further processing after delivery.

If applicable, the prices are solid metal prices without surcharges and VAT. Sales only to business customers.

Trade product, not a LAPP product.
