Rectangular connectors

Our EPIC® rectangular connectors can be individually assembled from the housing, insert and contact. There are two housing performance classes for you to choose from: EPIC® standard and EPIC® ULTRA. The suitable inserts are available as a fixed-pin variant and as a modular system. Of course we offer the right accessories for the housings and inserts.
