Rectangular connector modular system

Modular connector systems give you maximum flexibility in manufacturing individual connectors. We offer modules for power supply, signal control, data transmission and for pneumatic applications, which can be pushed into the available module frames in any combination and then mounted in a rectangular connector housing. The applications of hybrid, modular connectors are almost unlimited.
