Powerlock single-pole connectors

Perfect for transmission of very high currents

EPIC® POWERLOCK connectors are single-pin circular connectors for mobile power distribution, electric motors and generators. The connectors from LAPP are perfect for transmitting very high currents and are available as a screw or crimp version. Our connectors are color-coded and geometrically coded to prevent incorrect connections.

Categories

Filter

Reset

Filter

Filter

Reset

  • General information
    • Product type
      • Coupling connector
      • Cable connector
    • Brand
      • EPIC®
    • Contacts included
      • No
    • Design size
      • Powerlock F6 C
      • Powerlock D6 C
    • Packaging unit (PU)
      • 1.0
    • Scope of delivery
      • Order contacts separately
  • Electrical parameters
    • Rated current
      • 660 A according to IEC
    • Rated impulse voltage
      • 8 kV AC rms according to IEC 61984
    • Rated voltage
      • 1000 V AC rms / DC according to IEC
  • Product design
    • Connector housing design
      • Straight
    • Connector type
      • Drain
      • Source
    • Contact connection type
      • Crimp termination
    • Housing color
      • black
      • green
      • red
      • brown
      • gray
    • Locking type
      • Turning Lock
    • Marking
      • L1
      • Ground
      • L2
      • L3
    • Max. connectable conductor cross-section (mm2) (in2)
      • 240.0 mm²
    • Min. connectable conductor cross-section (mm2) (in2)
      • 35.0 mm²
    • Stripping length of the jacket
      • 42.0 mm
    • With protective conductor
      • No
      • Yes
  • Product features
    • Characteristics
      • Impact-resistant
    • IP protection class plugged in
      • IP 67
    • Min. number of plug cycles
      • 500
    • Operating temperature max.
      • 125.0 °C
    • Operating temperature min.
      • -30.0 °C
    • Protection class (IP), not installed
      • IP 20
  • Certifications and standards
    • Certificates
      • CE marking
      • UKCA marked
      • VDE certified
    • Product standard according to IEC
      • IEC 61984
    • VDE registration number
      • D042
Results (2)
