Signal connectors

For the transmission of sensitive signals

The EPIC® SIGNAL connectors are used for signal transmission in servo applications. The connectors are available in M17, M23 and M27 variants. The EMC screen contact reliably prevents electromagnetic interference. The gold-plated signal contacts reliably transmit the smallest currents and voltages.
