15361000
Railway cable; 1X1.5; EN 50264-3-1; Type M; U0/U: 1.8/3 kV; -45 - 120 °C; Electron beam cross-linked polymer compound; ; black
ÖLFLEX® TRAIN 361 1,8kV 1X1,5 BK
Add to product comparison
Price
130,83 €
(130,83 €/100 Metre)
Login for the stock enquiry.
Available. Find out the delivery date in the offer.
Benefits
- For the protection of people and property.
- Good chemical resistance
- Resistant to mechanical influences in harsh environmental conditions
- Compliant with standards for use in rail vehicles: fire safety and cable design requirements according to DIN EN 50264-3-1, type M; fire behaviour test according to DIN EN 45545-2, hazard levels HL1, HL2 and HL3.
- Extended temperature range
- Fire behaviour also certified in accordance with NF testing standards from AFNOR (depending on the item, see Technical Data).
- Reduced flame spreading increases the protection against damage to persons and property in the event of a fire
- Electron beam cross-linked insulating material enables use at very low and high temperatures (see technical data).
- Halogen free and highly flame retardant materials reduce the risk of flame propagation, high smoke density and toxic flue gases in the event of a fire.
Application
- For use in railway vehicles, for fixed installations and applications where limited movement may occur
- Wide range of uses in rail vehicles.
- Suitable for connecting lamps, heating equipment, switchgear, terminal boxes and power supply
- Typical areas of application are heaters, switchgear, connection boxes, lighting, etc.
- Also applicable within oily environments and areas with increased ambient temperature
- Can be used in dry, damp and, especially, harsh and oily environments.
- The electron beam cross-linked polymer compound is highly resistant to oils, fuels, alkalis and acids.
- Suitable for outdoor use.
